Rear Compartment Fuse Block

The rear compartment fuse block is

The rear compartment fuse block is located on the left side of the trunk behind a cover. Vehicles with eAssist do not have a rear compartment fuse block.

The vehicle may not be equipped

The vehicle may not be equipped with all of the fuses, relays, and features shown.
